Floating Marker & Mooring Buoys
DE Series Double-Ear Buoys
Double-ear floats from 2.2 kg to 33.5 kg buoyancy for two-point rigging.
DE series — double earDE01: Ø16cmDE02: Ø18cmDE03: Ø20cmDE04: Ø22cmDE05: Ø26cmDE06: Ø28cmDE07: Ø30cmDE08: Ø32cmDE09: Ø40cm
Nine sizes with two reinforced ears. Confirm the rigging method and quantity when requesting a quotation.
Product overview
Two ears, more rigging options.
DE buoys carry two reinforced ears, letting a line pass through or tie off on either side for stable, low-twist rigging.
Nine sizes from 2.2 kg to 33.5 kg buoyancy cover marker lines, swim zones and small moorings.
01DE01: Ø16cm
02DE02: Ø18cm
03DE03: Ø20cm
04DE04: Ø22cm
05DE05: Ø26cm
06DE06: Ø28cm
07DE07: Ø30cm
08DE08: Ø32cm
09DE09: Ø40cm
Specification Table
Complete DE Series Double-Ear Buoys specifications.
DE series — double ear (UP37)
| Model | Diameter | Weight | Eye Ø | Buoyancy |
|---|---|---|---|---|
| DE01 | 16 cm | 400 g | 1.1 cm | 2.2 kg |
| DE02 | 18 cm | 500 g | 1.3 cm | 3.13 kg |
| DE03 | 20 cm | 800 g | 2.2 cm | 4.29 kg |
| DE04 | 22 cm | 1,000 g | 2.2 cm | 5.71 kg |
| DE05 | 26 cm | 1,900 g | 1.5 cm | 8.38 kg |
| DE06 | 28 cm | 2,800 g | 1.6 cm | 11.78 kg |
| DE07 | 30 cm | 3,200 g | 1.5 cm | 14.48 kg |
| DE08 | 32 cm | 3,600 g | 2.2 cm | 17.15 kg |
| DE09 | 40 cm | 6,700 g | 2.2 cm | 33.47 kg |
Application Scenes
Where DE Series Double-Ear Buoys works.
Key options
- Two reinforced ears for flexible rigging
- Buoyancy 2.2–33.5 kg
- Nine sizes Ø16–Ø40 cm
- UV-stable polythene
- Low-twist line geometry
Related products
Continue within this product family.
Request a matched specification
Tell us the boat, berth and quantity.
We will confirm the appropriate model, available dimensions, customization and delivery path within one working day.
